| Number of stirring positions |
1 |
| Stirring quantity max. per stirring position (H2O) |
20 l |
| Motor rating output |
9 W |
| Direction of rotation |
right / left |
| Speed display set-value |
LCD |
| Speed display actual-value |
LCD |
| Speed control |
Turning knob |
| Speed range |
50 - 1500 rpm |
| Setting accuracy speed |
10 rpm |
| Stirring bar length |
30 - 80 mm |
| Self-heating of the set-up plate by max. stirring (RT:22°C/duration:1h) |
2 +K |
| Heat output |
1000 W |
| Temperature display set-value |
LCD |
| Temperature display actual-value |
LCD |
| Temperature unit |
°C |
| Heating temperature range |
room temp. - 500 °C |
| Heat control |
Turning knob |
| Temperature setting range |
0 - 500 °C |
| Temperature setting resolution of heating plate |
5 K |
| Connection for ext. temperature sensor |
PT1000, ETS-D5, ETS-D6 |
| Temperature setting resolution of medium |
1 K |
| Adjustable safety circuit |
100 - 650 °C |
| Set-up plate material |
ceramic |
| Set-up plate dimensions |
180 x 180 mm |
| Automatic reverse rotation |
yes |
| Intermittent mode |
yes |
| Viscosity trend measurement |
yes |
| Timer |
yes |
| Sensor in medium detection (Error 5) |
yes |
| Temperature measure range PT1000 |
-10 - 400 °C |
| Speed deviation (no load,nominal voltage, at 1500rpm + 25 °C) |
2 ±% |
| Heating rate (1l H2O in H1500) |
5 K/min |
| Heat control accuracy of heating plate (at 100°C) |
5 ±K |
| Heat control accuracy with ext. PT1000 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) |
0.5 ±K |
| Heat control accuracy with ETS-D5 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) |
0.5 ±K |
| Heat control accuracy with ETS-D6 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) |
0.2 ±K |
| Dimensions (W x H x D) |
220 x 88 x 354 mm |
| Weight |
4 kg |
| Permissible ambient temperature |
5 - 40 °C |
