REMI Orbital Shaking Incubators are designed for precise temperature control and simultaneous shaking applications required in fermentation studies, enzyme reaction s, life sciences, tissue culture and biotechnology, research labs.
These chambers are available in standard & GMP versions.

SALIENT FEATURES

• Brushless Induction Motor with variable frequency drive suitable for continuous operations
• Step-less variable frequency drive ensures gentle shaking start and maintains set speed
• The counterbalanced mechanism for high stability in an uneven load of different sized flasks
• Universal Shaking Platform to accommodate different sized assorted flasks
• Maximum shaking capacity “ 9 Flasks x 2000 ml
• Powerful fan motor for forced air circulation to maintain uniform conditions inside the chamber
• Machine filled PUF insulation to eliminate void pockets
• The unique design of the thermal barrier for better energy efficiency
• Heating by long SS tubular heaters
• Additional tray to store samples
• Chamber calibration port on the side
• Hermetically sealed Compressor with CFC free refrigerant (CIS“24 Plus)
• Microprocessor controller with 4 LCD display for display of shaking speed & temperature
• 9 programs memory
• Power failure and resumption recorded with data and time.
• High-temperature safety cut off & alarms for high / low set temperature
• Electrical circuit breaker
• Time delay for compressor switch on (CIS“24 Plus)
• Overload cut off relay for the compressor (CIS“24 Plus)
• Rounded inner chamber for easy cleaning
• Attractive door profile
• Optional
  • Touch screen display ( TFT ) with additional features(Details overleaf)
  • Validation protocol with IQ, OQ, PQ Documentation

TOUCH SCREEN DISPLAY

• 7-inch big color touch screen
• PLC (Programmable logic controller)
• The memory of 10,000 records
• Centronic interface to record Temperature, Date & Time by attaching Dot Matrix printer with adjustable print interval
• PC communication through REMI Datasoft
• Ethernet port
• Battery backup in case of power failure for display, alarms & off-line data logging (optional)
• Programmable cyclic timer for controlling illumination conditions

REMI ‘DATA SOFT’

• 7-inch big color touch screen
• PLC (Programmable logic controller)
• The memory of 10,000 records
• Centronic interface to record Temperature, Date & Time by attaching Dot Matrix printer with adjustable print interval
• PC communication through REMI Datasoft
• Ethernet port
• Battery backup in case of power failure for display, alarms & off-line data logging (optional)
• Programmable cyclic timer for controlling illumination conditions

OPTIONAL ACCESSORIES

To be Ordered separately

• Chamber illumination with the help of 2 Nos. fluorescent tubes
• Chamber illumination with 2 Nos. ultraviolet lights
• 24 hours Cyclic Timer for regulating illumination conditions
• Data logger for 8 Point temperature & Humidity recording with sensors printer interface and software
• Seven days circular chart recorder (single channel)
• Software as per 21 CFR Part 11 requirements
• PLC Based Control System with HMI Touch Screen
• Biometrics Magnetic Door Access for Secured Door opening with software to maintain a log
• Validation (mapping) consists of one cycle for the temperature at any one set point for 24 hours on empty and loaded condition
• Standby Refrigeration System
• GSM alert through SIM card

Supply: 220-240 Volts, 50 Hz Single Phase.
*Clamps to be ordered separately
