REMI Orbital Shaking Incubators are designed for precise temperature control and simultaneous shaking applications required in fermentation studies, enzyme reaction s, life sciences, tissue culture and biotechnology, research labs.
These chambers are available in standard & GMP versions.
SALIENT FEATURES
- Brushless induction motor with variable frequency drive suitable for continuous operations
- Step-less variable frequency drive ensures gentle shaking start and maintains set speed
- The counterbalanced mechanism for high stability in an uneven load of different sized flasks
- Universal Shaking Platform to accommodate different sized assorted flasks
- Maximum shaking capacity “ 9 Flasks x 2000 ml
- Powerful fan motor for forced air circulation to maintain uniform conditions inside the chamber
- Machine filled PUF insulation to eliminate void pockets
- The unique design of the thermal barrier for better energy efficiency
- Heating by long SS tubular heaters
- Additional tray to store samples
- Chamber calibration port on the side
- Hermetically sealed Compressor with CFC free refrigerant (CIS“24 Plus)
- Microprocessor controller with 4 LCD display for display of shaking speed & temperature
- 9 programs memory
- Power failure and resumption recorded with data and time.
- High-temperature safety cut off & alarms for high / low set temperature
- Electrical circuit breaker
- Time delay for compressor switch on (CIS“24 Plus)
- Overload cut off relay for the compressor (CIS“24 Plus)
- Rounded inner chamber for easy cleaning
- Attractive door profile
- Optional
- Touch screen display ( TFT ) with additional features(Details overleaf)
- Validation protocol with IQ, OQ, PQ Documentation
TOUCH SCREEN DISPLAY
- 7-inch big color touch screen
- PLC (Programable logic controller)
- A memory of 10,000 records
- Centronic interface to record Temperature, Date & Time by attaching Dot Matrix printer with adjustable print interval
- PC communication through REMI Datasoft
- Ethernet port
- Battery backup in case of power failure for display, alarms & off-line data logging (optional)
- Programmable cyclic timer for controlling illumination conditions
REMI ‘DATA SOFT’
- 7-inch big color touch screen
- PLC (Programmable logic controller)
- The memory of 10,000 records
- Centronic interface to record Temperature, Date & Time by attaching Dot Matrix printer with adjustable print interval
- PC communication through REMI Datasoft
- Ethernet port
- Battery backup in case of power failure for display, alarms & off-line data logging (optional)
- Programmable cyclic timer for controlling illumination conditions
OPTIONAL ACCESSORIES
To be Ordered separately
- Chamber illumination with the help of 2 Nos. fluorescent tubes
- Chamber illumination with 2 Nos. ultraviolet lights
- 24 hours Cyclic Timer for regulating illumination conditions
- Data logger for 8 Point temperature & Humidity recording with sensors printer interface and software
- Seven days circular chart recorder (single channel)
- Software as per 21 CFR Part 11 requirements
- PLC Based Control System with HMI Touch Screen
- Biometrics Magnetic Door Access for Secured Door opening with software to maintain a log
- Validation (mapping) consists of one cycle for the temperature at any one set point for 24 hours on empty and loaded condition
- Standby Refrigeration System
- GSM alert through SIM card
|
Model No.
|
CIS-24 Plus
|
|
Temperature Range & Accuracy
|
5°C to 60°C, ± 0.5°C
|
|
Internal Volume (Liters)
|
215
|
|
Platform Size
|
580mm x 600mm
|
|
Maximum Shaking Capacity (Volume x No. of flasks)*
|
100ml x 49, 150ml x 49, 250ml x 33, 500ml x 24, 1000ml x 15, 2000 ml x 9
|
|
Shaking Speed range (RPM)
|
20 to 250
|
|
Shaking Amplitude
|
25 mm
|
|
Internal Dimensions W x D x H (mm)
|
660 x 765 x 650
|
|
External Dimensions W x D x H (mm)
|
800 x 1150 x 1300
|
|
Temperature control
|
Microprocessor with PT-100 sensor
|
|
Display
|
4″ LCD Screen, Large size Display for ease of reading
|
|
Power Failure Alarm
|
Audio Visual Alarm
|
|
Door Open Alarm
|
Audio Alarm in case door open for over one minute
|
|
Temperature Variation Alarm
|
Set Temperature ± 2°C, Audio Visual Alarm
|
|
Illumination
|
8 Watts Fluorescent Tube
|
|
Internal Body Material
|
Stainless Steel – 304 grade (Standard Models), Stainless Steel – 316 grade (GMP Models)
|
|
External Body Material
|
Powder Coated CRCA Steel (Standard Models), Stainless Steel – 304 grade (GMP Models)
|
|
Insulation (CFC free polyurethane foam)
|
70 mm minimum for Body & 80 mm for Door
|
|
Noise Level
|
Less Than 65 db (A)
|
|
Recommended Voltage Stabilizer
|
VS-02
|
Supply: 220-240 Volts, 50 Hz Single Phase.
*Clamps to be ordered separately
