MLX-TR Plus - Magnus Laboratory Trinocular LED Microscope

• illumination System: Built-in-illumination base with pre-centered 6V 20W halogen light source coupled with an efficient collector lens system
• Focusing: Co-axial coarse and fine controls with a focus adjustment and fine adjustment knobs; Coarse Focus range 25mm
• Revolving Nosepiece: Quadruple revolving nosepiece based on precision ball-bearing mechanism with positive stop click
• Stage: Co-axial low drive mechanical stage (125mm x 145mm) (±5mm) with traverse area of 50mmx76mm(±5mm); Observation Tube: Trinocular 45 degree inclined rotatable through 360 degrees; Condenser: Abbe condenser with aperture iris diaphragm (N.A. 1.25) focusable with rack and pinion through 20mm and a continuously variable iris diaphragm with a removable blue filter for daylight observation. Rack and pinion mounted condenser holder
• Eyepiece (10x): WF 1 Ox (FN 18mm) paired eyepiece. The unique optical design of the compensating eyepiece provides relief from eye fatigue and renders color-compensated wide-field images of utmost clarity; Power Consumption: 100V-240V AC 50Hz (SMPS); Body: Aluminium die-cast body with all critical movements based on ball bearing and wire guides thereby ensuring smooth and precise manipulation
