• Stand

  Single mold sturdy stand with anti-rust materials. The ergonomic base for hand rest and greater stability.

• Viewing Body

  Siedentopf Binocular (Butterfly style) or Trinocular head, 45° inclined, 360° rotatable, with adjustable viewing height up to 40mm, IPD 48 - 75mm

• Eyepieces

  Widefield 10x/18mm with foldable eye guards, lockable, antifungal

• Nosepiece

  Reverse angle quadruple nosepiece (Ball bearing type) with click stops and rubber grip

• Objectives

  EP2 Plan Achromat DIN Infinity objectives 4x, 10x, 40x (spring loaded), 100x (spring loaded, oil), antifungal

• Mechanical stage

  Double plate stage 150 x 135mm, X-Y travel range 75mm x 40mm with low-height controls. Hard coated surface for scratch resistance. Double specimen holder.

• Condenser

  Substage Abbe condenser NA 1.25 with aspheric lens. Iris diaphragm with a blue daylight filter. Rack and pinion movements on metal guides

• Focusing

  Coaxial coarse and fine focus on ball drive system for smooth operation

• Illumination

  Intensity controlled LED (up to 50,000 hours of LED life)

• Electronics

  Universal input 100V - 240V AC, 50/60Hz. Built-in voltage stabilizer



  Accessories (Optional)

  • Pointers & Micrometer Reticules
  • Phase (Simple & Zernike), Polarizing, Fluorescence and Dark Field Kits
  • Dual Viewing Bridge
  • Quintuple Position Viewing Bridge
  • Auxiliary Objectives and Eyepieces
  • Cord Hanger Kit
  • Digital Cameras and Adapters
  • Soft Carrying Case

  Package Contents

  • Power Cable (6ft)
  • Cargille Immersion Oil
  • Spare bulb (20w version only)
  • Nylon Dust Cover & Cleaning Cloth
  • Styrofoam Casing

Configurations
