• Stand

  Ergonomically designed sturdy stand (aluminum die-cast)

• Viewing Body

  Binocular, Trinocular 30° and Ergonomic Tiltable Binocular tube (0°-25°), IPD 52-75mm

• Eyepiece

  Widefield 10x/22mm eyepieces with rubber eye guards, antifungal coatings

• Nosepiece

  Quadruple reverse angle turret (Ball bearing type) with rubber grip

• Objectives

  LW series Long working distance DIN Phase Plan Achromatic objectives 4x, 10x and 20x, antifungal coatings

• Mechanical stage

  Fixed plain stage 160mm x 240mm

• Condenser

  Long working distance Condenser NA 0.30, suitable for Phase contrast/BF with Phase contrast slider and telescope, Green and Blue filters. Specimen holders include 35mm Petri dish holder and two dish/sample holders (only with optional mechanical stage)

• Focusing

  Coaxial coarse and fine focusing mechanism. Fine focus graduation 2.0μm

• Illumination

  Transmitted Illumination system 6v30w Halogen with intensity control. Up to 500 hours of Halogen lamp life.

• Electronics

  Universal power supply (110V-240V) with a built-in voltage stabilizer



  Accessories (Optional)

  • Pointers & Micrometer Reticules
  • Phase and Fluorescence Kits
  • Auxiliary Objectives and Eyepieces
  • Digital Cameras and Adapters
  • Soft Carrying Case

  Package Contents

  • Power Cable (6ft)
  • Nylon Dust Cover & Cleaning Cloth
  • Instapack Packaging
  •


Configurations
