• Optical System

  Greenough

• Magnification

  4.4:1 Zoom Ratio

• Eyepieces

  Widefield 10x/18mm (interchangeable)

• Diopter Correction

  + / - 5 diopters

• Viewing Body

  Integrated Binocular, 45º, 52-74mm diopter adjustment

• Working Distance

  100mm

• Magnification Range

  8x to 35x Continuous

• Object Field Diameter

  6.6 to 28.5 mm

• Eye Guards

  Rubber, Retractable

• Illumination Control

  Incident / Transmitted ("Oblique" Settings) / Combined illumination control buttons with rheostat dial for light intensity control

• Incident Light

  + / - 30º Oblique illumination and variable intensity control dial

• Incident Light Method

  Maximum intensity (10 LEDs), front angled incident light (5 LEDs), rear angled incident light 5 (LEDs)

• Transmitted Light

  3-LED super bright glow screen, low heat emission

• LED Life

  Up to 25,000 hours

• Light Quality

  Homogeneous daylight (6500ºK), free of UV and IR emissions

• Power Supply

  Universal 100V - 240V, 50/60Hz integrated power supply with voltage flux stabilizer



  Accessories (Optional)

  • Pointers & Micrometer Reticules
  • Auxiliary Eyepieces
  • Polarizing Kit
  • 1.5x Auxiliary Objective
  • Soft Carrying Case

  Package Contents

  • Power Cable (6ft)
  • Nylon Dust Cover & Cleaning Cloth

Configurations
