• Stand

  Ergonomic sturdy stand made of anti-rust material

• Viewing Body

  Siedentopf Binocular or Trinocular head; 30° inclined, fixed; IPD 52- 75mm.

• Eyepiece

  Focusable Wide Field eyepieces 10x/22mm, with foldable eye guard, antifungal.

• Nosepiece

  Reverse angle quadruple nosepiece with click stops and rubber grip.

• Objectives

  ML series infinity corrected, DIN Plan Achromatic objectives 10x, 20x and 50x; antifungal, MaxLite (TM) coated; Optional 100x Dry objective.

• Focusing

  A coaxial coarse and fine focusing system with tension adjustment. Focus graduation is 2um per division.

• Illumination

  Koehler episcopic illumination system with diffuser; Halogen 6V-30W with intensity control; 100V - 240V universal power supply.

• Stage

  Fixed stage with specimen holder - 3 types (38mm, 55mm, 65mm). Optional mechanical stage.

• Electronics

  Universal power supply (110V-240V) with a built-in voltage stabilizer

• Optional

  100x Dry objective; Mechanical stage; Adapters for video and digital cameras



  Accessories (Optional)

  • Pointers & Micrometer Reticules
  • Phase and Fluorescence Kits
  • Auxiliary Objectives and Eyepieces
  • Digital Cameras and Adapters
  • Soft Carrying Case

  Package Contents

  • Power Cable (6ft)
  • Nylon Dust Cover & Cleaning Cloth
  • Instapack Packaging

Configurations
