Stand

Single mold sturdy stand with anti-rust materials. Extended base with hand rests for enhanced stability and comfort

Viewing Body

Siedentopf Binocular or Trinocular tube 30 Degree inclined, 360 Degree rotatable, Interpipullary distance adjustable 48-75mm. Vacuum coated Prism for better transmission and anti-fungus character.

(Viewing Height Adjustable to suit Individual User)

Eyepiece

Wide Field focusable paired eyepiece WF10x/20mm, with foldable eye guard, anti-fungus coating

Nosepiece

Reverse angle quadruple nosepiece (Ball bearing type) with click stops and rubber grip, anti-fungus coating. PAR-CENTERED PARFOCAL on CNC Machines.

Objectives

RP series DIN Infinity Corrected Plan Achromatic objectives 10x, 20x, 40x (spring loaded), 100x Oil (spring-loaded) anti-fungus coating. Specially corrected for Metallurgical

Mechanical Stage

Rackless X-axis, double plate mechanical stage size 200 x 160mm X/Y travel range 78 x 54mm. Low drive movement controls. Hard coated surface for scratch resistance.

Condenser

Sub-stage Abbe condenser NA 1.25 with aspheric lens and Iris diaphragm. Rack and pinion movements on stainless steel guides. Daylight blue filter provided.

Focusing

Co-axial coarse and fine focusing on ball drive system for smooth operation.

Illumination

Incident Transmitted - LED illumination with variable illumination control. Rechargeable Lithium-Ion Battery Provide long Hours of Battery Backup in case of electricity failure.

Electronics

Input 180v-240v AC, with removable imported cord.

PACKED in Styrofoam box, with operation manual, dust cover, cleaning cloth, power cord.
