Tablet Disintegration (NU-251)

VinSyst Disintegration Testers VDT Series determines whether Tablets or Capsules Disintegrate within the prescribed time when placed in a Liquid Medium. We offer Cost-Effective and Fully Calibrated Testers for testing the Disintegration Time of Tablets, Capsules, and other Solid Dosage Forms. It is a powerful Micro-Controller based Stepper Motor driven Technology that provides Uninterrupted and Faultless operation.

Specifications:

• Basket Assembly: 2 nos (Total 12 Glass Tubes)
• Digital System
• Rpm Speed Variable - 30 rpm
• Strokes/min - (30~32)/min
• Stroke height - (55±1)/mm
• Adjustable Timing Range
• The precision of Timing - ±0.5 min
• Temperature range 20-50°C
• The precision of Controlling Temperature - ±0.5ºC
• Motor - 24 Volt
• Heater - 125 watt
• Digital timer (buzzer system) - 999 minutes
• Temperature controller – Thermostatic
• Displacement - 55-58 mm
• Continual Working Time >24 hours
• Power consumption - 220/230v ac supply single-phase 50hz
