- Large Sample Room to Place 50mm Cuvette
- Digital Display the Measuring Value
- Auto Light Door and Zero Setting
- The Instrument Adopts Imported Tungsten Lamp
-
SPECTRAL
Model
3305
Optical System
Czerny-turner CT grating monochromator, 1200/mm
Wavelength Range
340-1020 nm
Spectral Bandwidth
6 nm
Wavelength Accuracy
± 3 nm
Wavelength Repeatability
<1 nm
Measurement Range
0-199.0%T, 0-1.999A, 0-1999C
Photometric Accuracy
0.5%T
Photometric Repeatability
± 0.3%T @220nm
Measuring Optical Path
100 mm
Stray Light
± 1.0%T (340 nm)
Stability
± 0.004 A/h(500 nm preheat 1 hour)
Display Modes
4 LCD
Basic Measurement
T, A, C
Light Source
6V10W
Operating Voltage
220V/110VAC,50-60Hz
Note: Specifications are subject to change due to continuous improvements.
| SPECTRAL | |
| Model | 3305 |
| Optical System | Czerny-turner CT grating monochromator, 1200/mm |
| Wavelength Range | 340-1020 nm |
| Spectral Bandwidth | 6 nm |
| Wavelength Accuracy | ± 3 nm |
| Wavelength Repeatability | <1 nm |
| Measurement Range | 0-199.0%T, 0-1.999A, 0-1999C |
| Photometric Accuracy | 0.5%T |
| Photometric Repeatability | ± 0.3%T @220nm |
| Measuring Optical Path | 100 mm |
| Stray Light | ± 1.0%T (340 nm) |
| Stability | ± 0.004 A/h(500 nm preheat 1 hour) |
| Display Modes | 4 LCD |
| Basic Measurement | T, A, C |
| Light Source | 6V10W |
| Operating Voltage | 220V/110VAC,50-60Hz |
Note: Specifications are subject to change due to continuous improvements.
