- Double Beam Optics
- 320 x 240 Dots Graphical LCD
- Auto Wavelength Setting at 0.1nm interval
- On-screen Standard and Kinetic Curve Display
- Tungsten/Deuterium Lamp can be turned ON/OFF Individually to Extend Lifetime
- Application Software provides complete control of the instrument from a computer through the built-in USB Port.
- Basic, WL Scan, Multi-Wavelength, Kinetic, Quantitative, DNA/Protein modes
- The pre-aligned design makes it convenient to change lamps
- Large Sample Compartment can accommodate 5-100 mm path- length cuvettes with optional holders. 8-Position Auto Cell hanger of 10 mm Path-length provided.
- Optional Sipper Pump
| SPECTRAL | |
| Mode | Basic, Wavelength Scan, Multi Wavelength, Kinetics, Quantitative, DNA/Protein |
| Wavelength Range | 190 – 1100 nm |
| Spectral Bandwidth(Vairiable) | 0.5/1.0/2.0/4.0/5.0nm |
| Optical System | Double Beam, Grating 1200 lines/mm |
| Wavelength Accuracy | ± 0.3nm |
| Wavelength Repeatability | ± 0.2 nm |
| Scanning Speed | HI, MED, LOW, MAX 3000 nm/min |
| Photometric Accuracy | ± 0.3 %T or ± 0.002A/h@1A |
| Photometric Range | 0 – 200 %T, -0.3 to 3A, 0 – 9999 Conc. |
| Stray Light | < 0.05 %T @ 220nm & 340nm |
| Stability | ± 0.001A/h @500 nm |
| Baseline Flatness | ± 0.001A (200 – 1000 nm) |
| Display | 5 Inches 320 x 240 Dots Graphical LCD |
| Sample Compartment | Standard 8 cell with automatic cell changer – 10 mm path-length. (50 mm & 100 mm path-length optional at extra cost) |
| Light Source | Halogen & Deuterium Lamps (Pre-Aligned) |
| Output | USB for PC Connectivity and Parallel Port for dot matrix printer |
| Power | 230 V±10% AC, 50 Hz |
| Dimensions(L x B x H) | 590 x 455 x 250 mm (Approx.) |
| Weight | 17.5 Kg. (Approx.) |
